Popis produktu

The latest in wireless technology transfer delivers up to 433 Mbps (5 GHz) and 150 Mbps (2.4 GHz) speeds Weatherproof and corrosion resistant, IP65 Simultaneous dual-band operation (2.4 GHz and 5 GHz) provides twice the bandwidth Supports WEP and WPA/WPA2 (TKIP and AES) data encryption Supports WMM (IEEE 802.11e QoS standard) prioritizing bandwidth for multimedia applications Powerful 7 dBi gain antennas, detachable, with RP-SMA female connector Supported modes: Access Point, Router, Repeater and WISP (Wireless ISP) Supports Wi-Fi Protected Setup (WPS) Included passive POE injector for up to 60 meters (200 feet) connection distance Easy installation through Web-based user interface Firmware upgradeable Three-Year Warranty
Standards IEEE 802.11ac (433 Mbps Wireless LAN) IEEE 802.11b (11 Mbps Wireless LAN) IEEE 802.11g (54 Mbps Wireless LAN) IEEE 802.11n (150 Mbps Wireless LAN) IEEE 802.3 (10Base-T Ethernet) IEEE 802.3u (100Base-TX Fast Ethernet)
General LAN/WAN port: 1 RJ45 10/100 Mbps data and power input port for passive PoE injector Flash: 64 MB Memory: 512 MB DDR2 VPN pass-through Reset button Ground (GND) connector Certifications: FCC Class A, CE, RoHS
Wireless Wireless channels EU (ETSI): 1-13, US (FCC): 1-11 Modulation technologies: - 11ac: 16QAM, 64QAM 128QAM 256QAM with OFDM - 11g/n: BPSK, QPSK, 16QAM, 64QAM, OFDM - 11b: DQPSK, DBPSK, DSSS, CCK Wireless security: - Open - WEP encryption (64/128 bit) - WPA PSK - WPA2 PSK - WPA2 mixed Data rates: - IEEE 802.11b (11 Mbps, 5.5 Mbps, 2 Mbps, 1 Mbps) - IEEE 802.11g (54 Mbps, 48 Mbps, 36 Mbps, 24 Mbps, 18 Mbps, 12 Mbps, 9 Mbps, 6 Mbps) - IEEE 802.11n (up to 150 Mbps) - IEEE 802.11ac (up to 433 Mbps) Max. transmit output power US (FCC): 28 dBm Max. transmit output power EU (ETSI): 13 dBm Antenna gain: 7 dBi Max. EIRP output power US (FCC): 35 dBm Max. EIRP output power EU (ETSI): 20 dBm
Router Supported WAN connection types: - Dynamic IP (DHCP for cable service) - Static IP - PPPoE (for DSL)
Power External power adapter: 24 VDC, 0.5 A Power consumption: 7 watts max.
LEDs Power WLAN/LAN Link/Act WLAN on WLAN Signal Strength Power
Environmental Dimensions: 428 (L) x 55 (W) x 55 (H) [mm] / 16.85 (L) x 2.17 (W) x 2.17 (H) [in] Weight: 0.26 kg (0.57 lbs) Operating temperature: -30 – 70°C (-22 – 158°F) Storage temperature: -40 – 70°C (-40 – 158°F) Operating humidity: 10 – 90% RH, non-condensing Storage humidity: 10 – 90% RH, non-condensing
Package Contents - High-Power Wireless AC600 Outdoor Access Point / Repeater - 2 external detachable dipole antennas - Pole mounting bracket - Quick installation guide - Ethernet Cat5 RJ45 cable - Installation CD - Power adapter - Passive PoE Injector - 2 Cable ties - Wall mount kit

---

Našli ste v tomto popise chybu? Prosím kontakujte nás na email: info@mader.sk
Rada výrobcov si vyhradzuje právo na zmenu niektorých parametrov, či vlastností bez predchadzajúceho upozornenia.
